High Density Gravity Flow Racking for Large Load Capacity Storage
High load-bearing gravity rail design ideal for high-throughput distribution, maximizing vertical cube utilization with multi-tier density.
Inquire Now
Built using cold-rolled structural steel, heavy-duty roller tracks, and high-tensile impact guides to provide frictionless gravity-fed movement for continuous inventory movement.
High load-bearing gravity rail design ideal for high-throughput distribution, maximizing vertical cube utilization with multi-tier density.
Inquire Now
Heavy-duty pallet and carton live racking fitted with zinc-plated dynamic steel roller tracks ensuring true First-In, First-Out throughput.
Inquire Now
Fully modular pitch-adjustable tracks suited for carton cases, plastic storage totes, and multi-SKU retail replenishment lines.
Inquire Now
Reinforced beam engineering with customized slope gradients (2.5° to 4°) for smooth glide speeds and anti-impact end-stops.
Inquire Now
High-density multi-tier configuration providing separated stocking and picking aisles for zero-congestion assembly environments.
Inquire Now
Engineered with dual-purpose versatility for bulk carton bins and heavy bottom pallet storage, integrated with precision mechanical brake rollers.
Inquire Now
Equipped with an ergonomic presentation tray tilt-shelf that speeds up pick rates for piece-picking, order processing, and kitting workcells.
Inquire Now
High-adhesion epoxy powder coat finish engineered specifically to withstand coastal humidity in Mombasa and refrigerated cold rooms.
Inquire NowA systematic analysis of why dynamic gravity flow beds replace traditional static shelving for high-turnover SKUs.
By establishing replenishment from the rear loading aisle while order picking is executed entirely from the front aisle, operators experience zero conflict between restocking personnel and order pickers. This completely removes forklift-pedestrian crossing risks and increases overall facility safety.
Products glide naturally via calibrated gravitational force (calculated standard slope angle of 3% to 5%) from loading point to discharge point. The first carton loaded is automatically the first case ready for dispatch, eradicating stock obsolescence, date-coding errors, and product degradation in pharmaceutical and perishable supply chains.
Carton flow racks eliminate intermediate transit aisles required by static shelving arrays. Because multiple lanes of dynamic roller beds are placed back-to-back and vertically tiered, storage density increases dramatically, enabling logistics operators to postpone expensive land acquisition and warehouse relocations.
Kenya serves as the primary multimodal logistics gateway for East and Central Africa. Here is how our engineered carton flow systems serve key economic corridors.
Fulfillment centers across Nairobi Industrial Area, Embakasi, and Baba Dogo experience surging volumes in daily parcel sortation. Our tilted pick trays and roller bed tracks allow warehouse staff to pick high-frequency items within an arm's reach, minimizing travel time by up to 50%.
Distribution facilities dispensing prescription medicines, vaccines, and diagnostic sets strictly demand First-In, First-Out (FIFO) compliance to guarantee zero expired units. Custom flow dividers and track lane retainers protect integrity across diverse medicine carton sizes.
Handling horticultural exports and chilled items requires robust galvanization and cold-grade plastic or aluminum roller assemblies. Our carton flow racks withstand operating environments from +2°C to deep freeze without track brittleness or corrosion.
Container Freight Stations (CFS) and dry ports operating along the Northern Corridor require high-throughput multi-tier case sorting systems that handle continuous container stripping, customs staging, and prompt cross-docking operations.
Understanding the operational pressures driving Kenyan supply chain directors away from static storage toward dynamic gravity intralogistics.
The concentration of premium logistics parks around Tatu City, Tilisi, and along the Eastern Bypass has led to escalating per-square-meter rental costs. Modern businesses can no longer afford wide, inefficient aisles for hand-picking. Carton flow systems condense pick faces, allowing companies to consolidate multiple warehouse leases into one optimized central facility.
Kenyan retail is undergoing rapid transformation, combining major supermarket supply chains with hyper-local duka shop replenishment. Distribution managers must handle high SKU assortments with short order cycle times. Dynamic flow racks provide continuous stock availability at the pick face, directly eliminating stockouts during peak ordering hours.
With power grid instability and high commercial kilowatt-hour tariffs in sub-Saharan Africa, gravity-fed carton flow systems provide a strategic competitive advantage. They deliver continuous, automated material movement entirely powered by natural gravitational force, requiring 0 kWh electricity and zero recurring software licenses.
A side-by-side engineering breakdown illustrating selectivity, picking efficiency, and footprint optimization.
| Storage System Type | Inventory Principle | Picking Throughput Speed | Footprint Space Utilization | Ideal Application Scenario |
|---|---|---|---|---|
| Heavy-Duty Carton Flow Racks | Strict FIFO (Gravity-Fed) | Maximum (Up to 300+ picks/hr) | High (75% floor area saved) | Fast-moving FMCG, Pharma, E-commerce, Kitting |
| Standard Selective Pallet Racking | FIFO / LIFO (Forklift reliant) | Moderate (Pallet unit level) | Low-Medium (Requires wide truck aisles) | Bulk pallet staging, low SKU diversification |
| Static Longspan Shelving | LIFO / Manual Search | Low (Pickers walk long distances) | Poor (High aisle-to-storage ratio) | Low-throughput archives, maintenance tool rooms |
| Pallet Live / Gravity Flow Systems | Strict FIFO (Heavy pallet) | High (Bulk pallet throughput) | Maximum (Deep multi-pallet lanes) | Beverage bottling, cold storage pallet staging |
Direct manufacturing execution, certified structural steel, and complete logistics packaging tailored for seamless Mombasa port customs clearance.
We eliminate trading middleman markups. Every carton flow rack is custom engineered using certified high-tensile Q235B/Q355B cold-rolled steel. Frame depths, roller track pitches, lane divider spacings, and load capacities (from 50 kg up to 1,500 kg per level) are engineered directly around your exact carton dimensions and unit loads.
Our production facilities utilize automatic CNC punch lines, precision roll-forming mills, and robotic welding cells. All surfaces undergo shot blasting, multi-stage acid pickling, phosphating, and automatic electrostatic powder coating to ensure durable resistance against corrosion, impact wear, and harsh industrial handling.
International shipping can result in handling damage if not properly protected. We bundle our beams, upright frames, and roller tracks with protective steel strapping, edge protectors, and waterproof plastic film. We supply complete shipping documentation (Bill of Lading, Commercial Invoice, Packing List, Certificate of Origin) to facilitate clean clearing via the Port of Mombasa.
Key information regarding importation, customs clearing, technical specifications, and site installation.
Manufacturing of standard customized carton flow racking generally requires 15 to 25 working days depending on order volume. Ocean freight transit to Mombasa Port (Kilindini Harbour) typically takes approximately 18 to 28 days. Goods can then be moved by road or the Standard Gauge Railway (SGR) freight service directly to the Nairobi Inland Container Depot (ICD) in Embakasi.
Yes. Our carton flow bed inserts and roller tracks can be engineered to retrofit into standard selective pallet rack upright frames. We supply universal drop-in bracket attachments and structural cross-tie beams that lock directly into your existing teardrop, box, or diamond slotted upright profiles without requiring field welding.
The standard incline angle for carton flow tracks is between 2.5 degrees and 4 degrees (approximately 30 to 50 mm pitch per meter of track length). Light plastic totes move on lower gradients, while textured corrugated fiberboard cartons require slightly steeper inclines. We carry out test simulations using your carton weights and base textures before shipping.
We supply complete mill test certificates (MTC), international material inspection test results, loading data declarations, and detailed component packing lists. These documents facilitate smooth processing under the Pre-Export Verification of Conformity (PVoC) program through accredited inspection bodies prior to shipping.
Our systems feature modular boltless snap-in or pinned connections for beams and track supports. We provide complete 3D installation blueprints, exploded assembly schematics, and step-by-step video instructions. Local maintenance and facility engineering teams can complete full installations quickly using standard hand tools.
Depending on beam span, support cross-members, and roller track density, standard levels carry from 200 kg to 800 kg. For heavy-duty industrial assembly parts and engine component staging, reinforced structural designs safely support up to 1,500 kg per beam level with zero track deflection.
Send our structural engineering team your warehouse dimensions, ceiling clearance heights, and unit load profiles. Receive a free comprehensive layout drawing, picking route optimization analysis, and factory-direct CIF Mombasa price quotation within 24 hours.
